Boxy Minimalist · boxy, longline, layers over a hoodie

Unstructured Button Overshirt

CubeShirt

260 GSM brushed cotton twill, convertible collar, 62 cm chest, 74 cm length, 7-button placket, two chest patch pockets, no fusing in the body

FRONT

BACK

Free vector flat

No account

The drawing above, front and back, as an editable vector — open it in Illustrator, Figma or Affinity and put your own graphics on it. Measurements aren't on the flat; they're in the tech pack.

The vector flat above is free and always will be. The tech pack — graded measurements, tolerances, fabric weights and construction — is the paid part.

Starting spec — make a sample before you order in bulk.

New to tech packs? Read how to make one, step by step →

Fabric

260

GSM · Heavyweight · range 230–300

Brushed cotton twill — 100% cotton. Peached face; piece-dyed then garment-washed so it hangs soft from the first wear (expect 2-3% shrink — wash before grading)

Trim: Collar and placket interlining · Lightweight woven fusible · 70 GSM

What does GSM mean? Read the fabric weight guide →

How it's made

Shoulder

Drop shoulder, 3.5 cm drop — Flat-felled, 1.2 cm

Neck

Convertible one-piece collar, fused, sits flat open or closed · rib height: 7 cm · topstitch: Edge-stitch 0.2 cm + 0.6 cm

Closure

Centre-front placket, 3.2 cm, seven 18L buttons · hardware: Corozo or matte resin, 4-hole, tonal

Sleeve hem

6 cm single-button barrel cuff, 6 cm

Body hem

2.5 cm turned hem, twin-needle. Straight hem all round — no shirttail curve; the straight hem is what makes it read as outerwear

Pockets

Two chest patch pockets, 13 x 14 cm, bar-tacked at the corners, no flaps

Side seams

Flat-felled, 1.2 cm

Stitch density spi

10 stitches per inch

Size chart

Garment laid flat · M is the sample size

Measure

XXL

A

Body length (HPS to hem) ± 1 cm

72.5

75.5

78.5

B

Chest width (1 cm below armhole) ± 1 cm

C

Hem width ± 1 cm

D

Across shoulder (seam to seam) ± 1 cm

E

Sleeve length (from shoulder seam) ± 1 cm

58.5

61.5

64.5

F

Sleeve opening (cuff, buttoned) ± 0.5 cm

14.5

15.5

16.5

G

Armhole (straight) ± 0.5 cm

O

Collar height (centre back) ± 0.3 cm

Make a shopper size chart from this template (PNG or Shopify) →Sample back from the factory? Check it against this tech pack →

Colourways

Bone

#DDD6C6

Washed Black

#2B2B2B

Faded Olive

#6B6F52

Trims & notes

• 18L buttons x9 (7 front, 2 cuff) + 2 spare

• Lightweight fusible (collar and placket only)

• Woven main label (back neck)

• Care/content label

• This is the easiest garment in the library to get right on sample one: no lining, no padding, no fusing in the body, no zip. If you are making your first ever production run, start here.

• Fuse the collar and placket only. Every first-timer who fuses the fronts ends up with something that feels like a uniform shirt.

• Straight hem, not a shirttail. It is a two-centimetre decision that changes whether the piece reads as a shirt or a jacket.

• Back print area: 30 x 26 cm, starting 12 cm below the yoke seam.
